Solis 3KW Hybrid Solar Inverter S6-EH1P3K-L-PLUS
Solis 3KW Hybrid Solar Inverter S6-EH1P3K-L-PLUS
Couldn't load pickup availability
The Solis S6-EH1P3K-L-PLUS 3kW Hybrid Solar Inverter is a powerful and intelligent energy storage solution designed for modern homes in India. This advanced hybrid solar inverter seamlessly integrates solar panels, the utility grid, generator input, and lithium battery storage to create a highly efficient solar panel system for home use. Ideal for a hybrid solar system for home, this inverter ensures uninterrupted power supply during outages with an ultra-fast backup switchover time of less than 4 milliseconds. It supports both Li-ion and lead-acid batteries in the 40–60V range, making it an excellent choice for a solar system with lithium battery.
With a maximum efficiency of 96.2%, two MPPT trackers, and support for up to 6kW of recommended PV array size, the Solis 3kW solar inverter maximizes energy harvest and reduces electricity bills. It offers 200% overload capability for 10 seconds, generator compatibility for extended backup, and dual backup ports to prioritize critical and non-critical loads. Its rugged IP66-rated enclosure and natural convection cooling ensure reliable operation even in harsh Indian climates.
The Solis 3kW hybrid inverter is fully compatible with net metering and rooftop solar systems installed under PM Surya Ghar: Muft Bijli Yojana, Ministry of New and Renewable Energy (MNRE) solar subsidy programs, enabling homeowners to significantly reduce installation costs while enjoying clean and affordable energy. Smart monitoring via LCD, Bluetooth, mobile app, and optional Wi-Fi provides complete visibility into system performance.
Technical Specifications
| Specification | Details |
|---|---|
| Model | S6-EH1P3K-L-PLUS |
| Rated Output Power | 3 kW |
| Recommended Max. PV Array Size | 6 kW |
| Max. Usable PV Input Power | 4.8 kW |
| Maximum Input Voltage | 500 V |
| MPPT Voltage Range | 90–435 V |
| Number of MPPTs | 2 |
| Battery Type | Li-ion / Lead-acid |
| Battery Voltage Range | 40–60 V |
| Max. Charge/Discharge Power | 3 kW |
| Max. Charge/Discharge Current | 70 A |
| Backup Switch Time | < 4 ms |
| Maximum Efficiency | 96.2% |
| EU Efficiency | 96.1% |
| Protection Rating | IP66 |
| Dimensions (W × H × D) | 335 × 560 × 227 mm |
| Weight | 21.6 kg |
| Communication | CAN, RS485, Bluetooth, App, Optional Wi-Fi |
| Operating Temperature | -40°C to +60°C |
